| Identification | More | [Name]
Barium zirconate | [CAS]
12009-21-1 | [Synonyms]
BARIUM ZIRCONATE
BARIUM ZIRCONIUM OXIDE
bariumzirconium(iv)oxide
bariumzirconiumtrioxide
zirconate(zro32-),barium(1:1)
BARIUM ZIRCONATE, NANOPOWDER, <50NM, 98.5%
BARIUM ZIRCONATE, POWDER, <10 MICRON
BARIUM ZIRCONIUM OXIDE, 99% (METALS BASIS)
zirconate, barium | [EINECS(EC#)]
234-546-8 | [Molecular Formula]
BaO3Zn | [MDL Number]
MFCD00014189 | [Molecular Weight]
250.72 | [MOL File]
12009-21-1.mol |
| Chemical Properties | Back Directory | [Appearance]
Light gray-buff powder. Insoluble in water and alkalies; slightly soluble in acid. | [Melting point ]
2500°C | [density ]
5.52 g/mL at 25 °C(lit.)
| [solubility ]
insoluble in H2O, alkaline solutions; slightly soluble in acid solutions | [form ]
powder
| [color ]
Off-white | [Specific Gravity]
5.52 | [Water Solubility ]
Insoluble in water. | [Exposure limits]
ACGIH: TWA 5 mg/m3; STEL 10 mg/m3
NIOSH: IDLH 25 mg/m3; TWA 5 mg/m3; STEL 10 mg/m3 | [InChI]
InChI=1S/Ba.3O.Zr/q+2;;2*-1; | [InChIKey]
DQBAOWPVHRWLJC-UHFFFAOYSA-N | [SMILES]
[Zr]([O-])([O-])=O.[Ba+2] | [Uses]
Manufacture of a white, easily colored silicone rubber compound having good heat stability at temperatures up to 500F; electronics. | [CAS DataBase Reference]
12009-21-1(CAS DataBase Reference) | [EPA Substance Registry System]
12009-21-1(EPA Substance) |
| Safety Data | Back Directory | [Hazard Codes ]
Xn | [Risk Statements ]
R20/22:Harmful by inhalation and if swallowed . | [Safety Statements ]
S28:After contact with skin, wash immediately with plenty of ... (to be specified by the manufacturer) . | [WGK Germany ]
1
| [RTECS ]
CR0875000
| [TSCA ]
Yes | [Storage Class]
13 - Non Combustible Solids | [Hazard Classifications]
Acute Tox. 4 Inhalation
Acute Tox. 4 Oral | [Safety Profile]
Moderately toxic by
ingestion and intraperitoneal routes.
Inhalation produces interstitial pneumonitis.
See also ZIRCONIUM COMPOUNDS and
BARIUM COMPOUNDS. | [Toxicity]
LD50 orl-rat: 1980 mg/kg AIHAAP 24,131,63 |
| Hazard Information | Back Directory | [Chemical Properties]
Light gray-buff powder. Insoluble in water and alkalies; slightly soluble in acid. | [Application]
Barium zirconate proton exchange membrane fuel cells and electrolyzer cells exhibit outstanding electrochemical performance and stability. They demonstrate high Faraday efficiency and exceptional stability within a temperature range of 450 to 600 degrees Celsius, under water vapor partial pressures of 0.5 to 0.7 atmospheres, and at high electrolyzer current densities of 0.5 to 2.0 amperes per square centimeter. These properties confer significant advantages over conventional barium cerate electrolytes.
 | [Flammability and Explosibility]
Notclassified | [reaction suitability]
reagent type: catalyst
core: zirconium | [References]
[1] WEI TANG. Sintering protonic zirconate cells with enhanced electrolysis stability and Faradaic efficiency[J]. Nature synthesis, 2025, 4 5: 592-602. DOI:10.1038/s44160-025-00765-z.
[2] PETER BABILO S. H T Uda. Processing of yttrium-doped barium zirconate for high proton conductivity[J]. International Journal of Materials Research, 2007, 6 1: 1322-1330. DOI:10.1557/JMR.2007.0163.
[3] DR. DONGLIN HAN. Detrimental Effect of Sintering Additives on Conducting Ceramics: Yttrium-Doped Barium Zirconate[J]. ChemSusChem, 2018, 11 23: 4102-4113. DOI:10.1002/cssc.201801837.
[4] YOSHIHIRO YAMAZAKI Sossina M H Raul Hernandez Sanchez. High Total Proton Conductivity in Large-Grained Yttrium-Doped Barium Zirconate[J]. Chemistry of Materials, 2009, 21 13: 2755-2762. DOI:10.1021/cm900208w.
|
|
