1170-02-1

Ethylenediamine-N,N'-bis((2-hydroxyphenyl)acetic acid)(1170-02-1) IR2

Product NameEthylenediamine-N,N'-bis((2-hydroxyphenyl)acetic acid)

Molecular FormulaC18H20N2O6

Molecular Weight360.37

InChIInChI=1S/C18H20N2O6/c21-13-7-3-1-5-11(13)15(17(23)24)19-9-10-20-16(18(25)26)12-6-2-4-8-14(12)22/h1-8,15-16,19-22H,9-10H2,(H,23,24)(H,25,26)

InChIKey PZZHMLOHNYWKIK-UHFFFAOYSA-N

SmilesC1(C=CC=CC=1O)C(C(=O)O)NCCNC(C(=O)O)C1C=CC=CC=1O

Request For Quotation

¹HNMR

IR1

IR2

Ethylenediamine-N,N'-bis((2-hydroxyphenyl)acetic acid)(1170-02-1) IR2
Mass

MS-NW-2553
2,2'-(ethylenediimino)bis((o-hydroxyphenyl)acetic acid)
C18H20N2O6          (Mass of molecular ion:    360)

   Source Temperature: 230 °C
   Sample Temperature: 220 °C
   Direct, 75 eV

      15.0       1.5
      17.0       6.1
      18.0      30.1
      26.0       1.3
      27.0       4.2
      28.0       7.9
      30.0      14.2
      37.0       1.3
      38.0       2.9
      39.0       9.3
      40.0       1.8
      41.0       3.0
      42.0       5.9
      43.0       2.3
      44.0       7.8
      45.0       1.3
      50.0       6.0
      51.0      12.7
      52.0       6.2
      53.0       1.6
      54.0       1.6
      55.0       1.4
      57.0       1.2
      62.0       1.8
      63.0       5.1
      64.0       3.4
      65.0       5.3
      66.0       4.2
      67.0       1.1
      69.0       1.2
      70.0       9.5
      71.0       1.6
      74.0       1.5
      75.0       1.8
      76.0       3.5
      77.0      18.4
      78.0      25.0
      79.0       4.2
      89.0       2.8
      90.0       3.4
      91.0       8.5
      92.0       2.3
      93.0       4.1
      94.0       4.7
      95.0       1.9
     102.0       3.0
     103.0       2.8
     104.0       3.8
     105.0       8.3
     106.0      13.2
     107.0      15.3
     108.0       2.0
     115.0       1.0
     116.0       1.1
     117.0       2.1
     118.0       6.6
     119.0      10.1
     120.0      14.0
     121.0      12.8
     122.0       8.4
     123.0       1.6
     130.0       1.6
     131.0       4.7
     132.0       8.1
     133.0      13.4
     134.0      29.4
     135.0      11.5
     136.0       1.6
     145.0       4.1
     146.0       6.2
     147.0       6.8
     148.0       6.4
     149.0       6.1
     150.0       1.0
     151.0       1.5
     152.0       2.1
     159.0       1.3
     160.0       2.0
     161.0       2.5
     162.0       3.0
     163.0       2.3
     164.0       1.7
     165.0       1.2
     170.0       1.3
     171.0       2.0
     172.0       2.3
     173.0       2.6
     174.0       1.6
     175.0       1.4
     176.0       1.0
     181.0       2.1
     188.0       1.2
     189.0       6.3
     190.0       4.6
     191.0     100.0
     192.0      15.4
     193.0       1.6
     236.0       1.7
     238.0       1.2
     264.0       2.0
     265.0       1.0
     280.0       1.3
     322.0       2.2
     324.0       2.4
